Discount Eligibility:Can be combined with other plastic sheet products. Discounts are automatically applied at checkout. Full plastic sheet stock (24 x 49) can be cut into half sheets (24 x 24) or quarter sheets (12 x 24) at no additional charge.
5-9 full sheets: 10% | 10-19 full sheets: 20% | 20+ full sheets: 25%
Thin but durable, the Duets Contours microsurfaced flexible engraving stock is designed to deliver the prominent look of engraved signage applied to curved surfaces. Engravable substrates are available with or without adhesive and in several color and finish combinations.
Specifications:
Material: Microsurfaced impact modified acrylic
Finish: Matte non-glare, Gloss, Brushed Metal, Patterned, Brushed Satin
Sheet Size: Full: 24” x 49”, Half: 24” x 24”, Quarter: 12” x 24”
Full sheets can be cut into Half or Quarter sheets at no additional cost.
Engraving Methods: Laser, Rotating Carbide
Cutting Depth: .020” (0.5mm)
Manufacturer: Gemini
|
Applications:
- Awards & Recognition
- Interior Signage
- Interior Branding
- Retail Display
- Trophies, Awards, & Plaques
|
Characteristics:
- Front engravable
- Adhesive backing options
- Shears, scores, drills (1/8? not recommended for shearing or scoring)
- Saws
- Bondable
- Vector cut
- Hot stamp, silk screen
- UV-LED Printable
|
Duets Contours Laser Settings
While every laser is different, here are recommended laser settings to try out using the Duets. We recommend these settings to be adjusted for best results. Settings vary by age, make and model of laser. Request a free sample to test on your own laser engraving equipment with no risk or requirement to purchase sample stock.
| 35 Watt Laser |
50 Watt Laser |
75 Watt Laser |
120 Watt Laser |
|
Raster power: 35
Raster speed: 100
Vector power: 30
Vector speed: 20
|
Raster power: 25
Raster speed: 100
Vector power: 22
Vector speed: 20
|
Raster Engraving:
300 DPI 90% Speed, 40% Power
600 DPI 90% Speed, 25% Power
Vector Cutting:
25% Speed, 40% Power (1/16” Thickness)
15% Speed, 50% Power (1/8” Thickness)
|
Raster Engraving:
300 DPI, 90% Speed, 35% Power
600 DPI, 90% Speed, 20% Power
Vector Cutting
20% Speed, 40% Power (1/16” Thickness)
15% Speed, 50% Power (1/8” Thickness)
|
Product Documents
Request Free Duets SamplesGemini DuetsTactiles® ADA Color Contrast Guide
Gemini Duets Product Selection Guide
Gemini Laser Settings Guide
Gemini Acrylic MSDS
Gemini Acrylic Technical Data
Gemini LEEDS Certificate
Gemini Duets-Rowmark Cross Reference Guide
Cert of Compliance Buy American Requirements
